Lenovo Gaming Laptop Legion 5 15IAX10 U9-275HX 32GB /1TBSSD/8GB /RTX-5070/15.1"WQXGA/165Hz/DOS /BLK/RGB-BKLT/ENG

Legion 5 15IAX10

Explore Your Passions. Elevate Your Game.

Processor: Intel Core™ Ultra 9 275HX, 24C (8P + 16E) / 24T, Max Turbo up to 5.4GHz, 36MB Intel® Smart Cache
AI PC Category: AI-Powered Gaming PC
NPU: Integrated Intel® AI Boost, up to 13 TOPS
Graphics: NVIDIA GeForce RTX™ 5070 8GB GDDR7, Boost Clock 2347MHz, TGP 115W, 798 AI TOPS
Chipset: Intel® HM870 Chipset
Memory: 2x 16GB SODIMM DDR5-5600
Memory Slots: Two DDR5 SODIMM slots, dual-channel capable
Max Memory: Up to 32GB DDR5-5600 offering
Storage: 1TB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot: Two M.2 2280 PCIe® 4.0 x4 slots
Max Storage Support: Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each
Optical: None
Card Reader: No Card Reader
Audio Chip: High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers: Stereo speakers, 2W x2, audio by HARMAN, optimized with Nahimic Audio
Microphone: 2x, Array
Camera: 5.0MP with E-shutter
Battery: 80Wh
Power Adapter: 245W Slim Tip (3-pin)
Special Features: AI Chip: LA3
Display: 15.1" WQXGA (2560x1600) OLED 1000nits (peak) / 500nits (typical) glossy, 100% DCI-P3, 165Hz, Dolby Vision®, DisplayHDR™ True Black 600
Touchscreen: None
Screen-to-Body Ratio: OLED models: 90% AAR (active area ratio)
Color Calibration: Factory Color Calibration
Pen: Pen Not Supported
Keyboard: 24-Zone RGB Backlit, English (UK)
Touchpad: Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Dimensions (WxDxH): 344.9 x 255.35 x 19.95-21.54 mm (13.58 x 10.05 x 0.79- 0.85 inches)
Weight: Starting at 1.9 kg (4.19 lbs)
Case Color: Eclipse Black (with 24-Zone RGB Backlit Keyboard)
Case Material: Aluminium (Top), PC-ABS (Bottom)
Surface Treatment: Aluminium Stamping (Anodized with Sandblasting)
Operating System: None
Bundled Software: None
WLAN + Bluetooth: Wi-Fi® 7, 802.11be 2x2 + BT5.4
WWAN: WWAN Not Supported
Ethernet: 100/1000M (RJ-45)
Standard Ports: 2x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 95-100W and DisplayPort™ 2.1 1x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with DisplayPort™ 2.1 1x HDMI® 2.1, up to 8K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45) 1x Slim tip Power connector
Docking: Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for Legion 5 15IAX10
Security Chip: Firmware TPM 2.0 Enabled
Fingerprint Reader: No Fingerprint Reader
Other Security: E-shutter
Included Upgrade: None
Bundled Accessories: None
Green Certifications: ErP Lot 3 RoHS compliant
Other Certifications: TÜV Rheinland® Flicker Free TÜV Rheinland® Low Blue Light (Hardware Solution)
